CNC Spindle Chiller 60HZ CW-5000 for 3kW to 5kW Spindle

CNC Spindle Chiller 60HZ CW-5000 for 3kW to 5kW Spindle

CNC spindle chillers offer effective cooling solutions with a power range of 3kW to 5kW and cooling capacities from 600W to 42,000W.
Get A Quote

Why Use CNC Spindle Coolers?

Improves Machine Efficiency

The selection of the right kind of spindle is a crucial aspect of CNC machining to enable precision, efficiency, and long-lasting performance.

Stable Operating Temperature

CNC spindle chiller has a constant working temperature which is essential for high precision machining. The spindle performs dynamically, independent of load or conditions.

Reduce Thermal Deformation

It can adequately reduce the temperature of the spindle and adjacent parts, and stably control the temperature of this machine tool within a suitable range to reduce thermal deformation so as to ensure processing accuracy.

Reduce Noise and Vibration

Good cooling can reduce the thermal expansion and deformation of the spindle, thereby reducing noise and vibration during operation and improving the stability of the equipment.

The Latest Laser Water Chiller

Here you can find the CNC water chiller that suits you
60Hz CW-5000 Industrial Water Chiller Small Mini Chiller Laser Water Chiller for Laser Machines Cooling VIEW DETAILS

60Hz CW-5000 Industrial Water Chiller Small Mini Chiller Laser Water Chiller for Laser Machines Cooling

CW-3000 Built-in Water ChillerLong Service LifeLong Service Lifeindustrial Water Cooling Circulation Chiller VIEW DETAILS

CW-3000 Built-in Water ChillerLong Service LifeLong Service Lifeindustrial Water Cooling Circulation Chiller

Hand-Held All-In-One 1500/2000 Watts Welding Machine with Integrated Laser Convenient Chiller Cabinet for Welding Equipment VIEW DETAILS

Hand-Held All-In-One 1500/2000 Watts Welding Machine with Integrated Laser Convenient Chiller Cabinet for Welding Equipment

HL-1500 Custom Industrial Fiber Laser Chillers Air-Cooled Water Chiller with Pump for Laser Tube Cooler VIEW DETAILS

HL-1500 Custom Industrial Fiber Laser Chillers Air-Cooled Water Chiller with Pump for Laser Tube Cooler

Specifications of CNC Spindle Chiller CW-5000

Model
CW-5000TG
CW-5000DG
CW-5000TI
CW-5000DI
Voltage
AC 1P 220-240V
AC 1P 110V
AC 1P 220-240V
AC 1P 110V
Frequency
50/60Hz
60HZ
50/60Hz
60HZ
Working
0.4-2.7A
0.4-5.18A
0.6-2.9A
0.6-5.38A
Rated power of the whole machine
0.45/0.47KW
0.49KW
0.5/0.51KW
0.51KW
Compressor
0.37/0.39KW
0.38KW
0.37/0.39KW
0.38KW
0.5/0.53HP
0.51HP
0.5/0.53HP
0.51HP
Nominal
2995Btu/h
0.9KW
755Kcal/h
Water pump
0.03KW
0.88KW
Maximum head
13M
25M
Maximum flow rate
13L/min
25L/min
Refrigeran
R134a
Temp Accuracy
±0.3℃
Restrictor
Capillary
Inlet and outlet
φ10Copper Tsui Pagoda(default)/φ8Connector/φ10Connector/φ
12Connector
Water tank capacity
6L
Machine dimensions
Length *Width *Height 560*285*470mm(L×W×H)
Packaging size
Length *Width *Height 660*390*520mm(L×W×H)
Net weight
20Kg
21Kg
24Kg
23Kg
Gross weight
23Kg
24Kg
27Kg
26Kg
Security protection
Water flow protection,Water temperature ultra-high alarm,Water
temperature ultra-low alarm,Compressor overload protection,Room
temperature ultra-high alarm

Frequently asked questions about 60hz CW-5000 industrial water chillers

How to prevent my laser chiller from freezing?

For users living in high latitude areas especially in winter, they often face the frozen water problem. To prevent the chiller from freezing, they can add an optional heater or add anti-freezer in the chiller. For detailed use of the anti-freezer, it is suggested to contact our customer support team
We accept OEM of this series of CNC spindle chiller, please contact me for more product data .
Our professional engineers communicate with video and offer an one-year warranty (due to product quality issues) .
Delivery Period 10-20 days , support factory delivery and FOB .

When To Use CNC Spindle Chiller?

CNC spindles rotate at extremely high speeds to meet the demands of machining. Overheating a spindle can cause serious problems, some of which can be devastating to the spindle components.
Overheating a spindle often causes new sounds and vibrations. If you hear or feel something unusual, stop the spindle immediately.
Tools will change color. Look for darkening where the tool contacts the workpiece.
When a spindle begins to overheat, it will work less accurately and will not be able to hold tight tolerances. The spindle will not be able to reach higher speeds.
